Hubble images of Mars show the effects of global-scale dust storms on Mars. (credit: NASA, J. Bell (Cornell), M. Wolff (SSI), and the Hubble Heritage Team (STScI/AURA))

Mars atmospheric dust and human exploration

by Joel S. Levine, D. Winterhalter, R. Kerschmann, D. W. Beaty, B. L. Carrier, and J. W. Ashley
Monday, February 5, 2018

A major surprise of the Apollo Moon missions was the deleterious impact of lunar dust on the astronauts, their spacesuits ,and other equipment, and even inside the Command/Service Module during their return to Earth. Lunar dust permeated everything and impacted mechanical systems. The dust on the Moon’s surface was disturbed by the routine actions of the astronauts as they walked and performed their exploration of the lunar surface. Apollo 17 astronaut Gene Cernan, who along with Harrison Schmitt, were the last humans to walk on the Moon, had some very illuminating observations about lunar dust during his post-flight technical debrief:

I think dust is probably one of our greatest inhibitors to a nominal operation on the Moon. I think we can overcome other physiological or physical or mechanical problems except dust.

One of the most aggravating, restricting facets of lunar surface exploration is the dust and its adherence to everything no matter what kind of material, whether it be skin, suit material, metal, no matter what it be and its restrictive friction-like action to everything it gets on.

On Mars, surface and atmospheric dust may be even more detrimental to the human health and exploration than on the Moon if only because much longer expected exposures. The Apollo 17 astronauts spent a total of 75 hours on the Moon with their three extravehicular activities (EVAs) lasting a total of 22 hours and 4 minutes. By comparison, astronauts on Mars may spend up to 500 days on the surface of the Red Planet with EVAs of much greater duration than the Apollo astronauts, thus greatly extending the exposure time to atmospheric dust on Mars. In addition, the atmosphere of Mars includes a myriad of trace chemically active atmospheric gases that can lead to the production of toxic species. These may be deposited to the surface of Mars and directly on atmospheric dust particles.

A major finding of the Viking mission was the discovery of a persistent atmospheric background of dust ranging in diameter from less than 1 to more than 10 micrometers, resulting in an atmospheric dust opacity (tau) ranging from a few tenths to more than one at visible wavelengths. This persistent background of fine dust is responsible for the pinkish-reddish color of the atmosphere of Mars. During dust storms, the opacity of atmospheric dust can increase to a tau of more than three.

The surface of Mars is very dusty, covered with unconsolidated soil and dust that is readily transported into the atmosphere by horizontal and vertical winds. Mars is well known for its localized, regional, and planetary-scale dust storms. An an example, see the two photographs of Mars taken by the Hubble Space Telescope shown above: the left photograph taken on June 26, 2001 shows a “clear” Mars and the right photograph taken on September 4, 2001 shows Mars almost obscured by airborne dust. Localized, small-scale dust devils are also a regular feature of the Mars atmosphere, as shown below. Measurements of a regional dust storm in 1977 obtained by the Viking Orbiters led to an estimate of the mass of dust associated with this regional storm of about 430 million metric tons (see Martin, T. Z., 1995: J. Geophys. Res., 100, pp. 7509–7512). Viking Orbiter measurements were also used to deduce the mass of atmospheric dust associated with a localized dust storm near Solis Planum as about 13 million metric tons of dust lofted into the atmosphere (Martin, 1995).

Mars atmospheric and surface dust must be assessed for its impact on human health, the operation of Mars surface systems (e.g., spacesuits, habitats, ascent rockets, etc.) and surface operations and exploration (e.g., reduced atmospheric visibility, limited EVAs, hampering of regular habitat maintenance, etc.). Two earlier studies have considered the impact of Mars atmospheric dust on human exploration: Safe on Mars: Precursor Measurements Necessary to Support Human Operations on the Martian Surface published by the National Research Council (NRC) in 2002 and An Analysis of the Precursor Measurements of Mars Needed to Reduce the Risk of the First Human Mission to Mars published by the Mars Exploration Program Analysis Group (MEPAG) in 2005.

The NRC and MEPAG reports discussed the impact of Mars atmospheric dust on human health, including astronauts inhaling airborne particulate matter, toxic metals (e.g., hexavalent chromium, a highly toxic form of chromium in Mars soil and airborne dust), and potentially toxic atmospheric gases. In 2008, after the publication of the NRC and MEPAG Mars reports, the Phoenix Mars lander discovered compounds of perchlorate in the soil of Mars. The presence of perchlorate in the soil of Mars has now also been confirmed by soil measurements obtained by the Curiosity Mars rover. Perchlorate has been shown to interfere with the normal iodide uptake by the thyroid gland, and thus has been added to the list of potential toxic compounds in the soil of Mars.

Due to concern of the possible negative impacts of Mars dust on human health and the human exploration and surface operations on the Red Planet, the NASA Engineering and Safety Center (NESC) organized and held a workshop titled “Dust in the Atmosphere of Mars and Its Impact on Human Exploration” at the Lunar and Planetary Institute in Houston on June 13–15, 2017. Approximately 100 participants, including Mars scientists, mission engineers, mission architects and mission planners, medical researchers, and students attended the workshop. In a series of invited plenary papers, specialists reviewed the chemical, physical, and electrical properties of Mars atmospheric dust, the evolution, nature and occurrence of localized, regional and planetary-scale dust storms, the human health effects of Mars atmospheric dust, including inhalation of and potential toxicity of dust particles and the impact of Mars atmospheric dust on surface systems and on surface operations. Abstracts of the eight invited plenary papers and two dozen contributed papers are available on the conference website.

Workshop participants identified a number of gaps in our knowledge of dust in the atmosphere of Mars and its impact on human health and on human surface operations. Some of these knowledge gaps include:

1. The particle size distribution and density of atmospheric dust in “clear” and dust storm conditions;
2. The chemical composition of atmospheric dust, including the identification of possible toxic compounds;
3. The electrical nature of Mars atmospheric dust particles and how potential electrical charges on dust particles may be dissipated;
4. How to better predict the occurrence, location, severity, and duration of dust storms on Mars;
5. To understand the impact of Mars dust in human respiration in a reduced gravity environment over the extended periods of time that the astronauts will spend on the surface of Mars; and
6. To better understand the role of the omnipresent atmospheric dust in the potential transport of Earth microorganisms around Mars (forward contamination) and the role of atmospheric dust in transporting possible Mars microorganisms back to Earth with the astronauts and their equipment (back contamination).

In the report to the NESC, the workshop organizers recommended how these gaps in our understanding may be addressed prior to humans setting foot on Mars using future robotic missions presently being planned and by laboratory experimentation and computer modeling simulations.

Dr. Joel S. Levine organized and chaired the NASA Engineering and Safety Center (NESC) Workshop on Dust in the Atmosphere of Mars and Its Impact on Human Exploration. Levine is Research Professor in Applied Science at the College of William and Mary in Williamsburg, Virginia. Levine joined the William and Mary faculty in 2011 after a 41-year career at NASA Langley Research Center in Hampton, Virginia, as Senior Research Scientist in the Science Directorate and as Mars Scout Program Scientist in the Mars Exploration Program at NASA Headquarters. In the 1970s, Levine developed models of the Mars atmosphere for the Viking Project Scientist that were utilized in the successful soft landings of the Viking 1 and 2 landers in 1976. In 2017, during the centennial anniversary of NASA Langley, Levine was inducted into the NACA/NASA Langley Research Center Hall of Honor as the youngest of its 37 members.
